LD Systems STINGER 28 G3 Passive 2 x 8 Inch 2-Way Bass-Reflex PA Loudspeaker

Engineered for rock-solid reliability day in, day out this passive 2-way loudspeaker is a truly professional performer. With its multi-purpose bass reflex construction it is equally suitable for fullrange, satellite or monitor use in live PA systems and permanent installations. The Stinger 28 G3 boasts a mighty 400 watts RMS power handling and 125 dB maximum sound pressure. It is loaded with dual custom designed 8” woofers and a BMS compression driver delivering a punchy low end and smooth, crisp highs. The HF waveguide has been designed using BEM, the numerical modeling of sound radiation and propagation. It reduces floor and ceiling reflections, effectively eliminates side lobes and achieves a controlled uniform coverage pattern. The Stinger 28 G3 is designed to be a real workhorse throughout. The enclosure is made of rigid birch ply and coated with ultra tough polyurea for extraordinary strength and durability. Sporting a steel front grille, Dual-Tilt pole receptacle, multiple suspension points and ergonomic handles the Stinger 28 G3 is an attractively priced choice for truly professional sound reinforcement. A large selection of accessories facilitate live and installed applications.

Key Features

• 2-way passive 2 x 8” bass reflex PA speaker
• 400 watts RMS power handling
• 125 dB maximum SPL
• 2 x 8“ custom woofer and BMS compression driver
• BEM optimized HF waveguide for uniform coverage
• Birch ply cabinet with ultra rugged polyurea finish and M10 suspension points
• Shock-resistant front grill provides maximum speaker protection
• 36 mm Dual-Tilt pole receptacle for 0 or 5 mounting angles
• Large selection of smart installation and transport accessories

Technical Specifications

Product type
PA loudspeaker
Type
passive
Low/mid driver dimensions
2 x 8”
Woofer size
2 x 203.2 mm
Woofer magnet
Ferrite
Woofer brand
Custom-made
Woofer voice coil
2”
Woofer voice coil (mm)
50.8 mm
Horn
BEM optimized CD Horn
HF driver dimensions
1”
HF Driver Size
25.4 mm
HF driver magnet
Ferrite
HF driver brand
BMS
HF driver voice coil
1”
HF Driver Voice Coil
25.4 mm
Dispersion (H x V)
90 x 50
Load rating (RMS)
400 W
Peak power
800 W
Frequency response
58 – 20000 Hz
SPL (1W/1m)
99 dB
Max. SPL
125 dB
Impedance
8 Ohm(s)
Protection circuits
HF Driver
Loudspeaker inputs
1
Speaker input connections
Speakon compatible
Loudspeaker outputs
1
Speaker output connections
Speakon compatible
Speakers per amplifier channel (DSP44/45K)
3
Cabinet material
12 mm Plywood
Cabinet surface
Polyurea
Cabinet construction
Bass Reflex
Width
270 mm
Height
756 mm
Depth
290 mm
Weight
19,3 kg
