City Theatrical Multiverse Wireless DMX/RDM Transmitter with Bluetooth Radio Receiver Built-In, 900 MHz Limited Edition Sale Online

City Theatrical Multiverse Wireless DMX/RDM Transmitter with Bluetooth Radio Receiver Built-In, 900 MHz

Introducing the Multiverse® Transmitter 900MHz (x2) – a groundbreaking wireless DMX/RDM device that opens up a new world of possibilities. Please note that this product is licensed for use in North America only.

With an Ethernet input, this transmitter can receive Streaming ACN (sACN) or Art-Net and transmit up to eight universes of user-selectable DMX/RDM. It uses minimal radio energy and is more efficient than a typical single-universe wireless DMX transmitter.

The Multiverse Transmitter has a built-in Bluetooth radio receiver to communicate with City Theatrical’s award-winning DMXcat® app, which can be used on a user’s smartphone. This feature allows you to remotely control any lighting fixture that is part of the Multiverse setup, including fixtures with a Multiverse Module inside, those receiving data from a Multiverse Node, or any wired fixture downstream of those devices.

Additionally, the Multiverse Transmitter is Wi-Fi enabled, so it can be controlled from tablet-based Wi-Fi lighting controllers such as Luminair.

Technical Specifications

Length
196.9mm (7.75 in)
Width
101.5mm (4.0 in)
Height
47mm (1.85 in)
User Interface
DMXcat app (for iPhone, Android, or Amazon Fire), free download
Construction
Die Cast Aluminum
Antenna
RP-SMA Female
AC
powerCON TRUE1 in/thru
DC
Locking DC Jack, 5.5mm x 2.1mm, center positive, 12.1mm mating depth; EtherCON
Power
100-240VAC 50/60Hz, 5-30VDC, PoE Class 0, 0.5W (maximum)
Broadcast Power
3.2mW, 10mW, 32mW, 100mW
Broadcast Modes
Adaptive, Full, Low, Mid, High, Max
DMX Burst Mode
Auto Dynamic
Ethernet Protocols
802.11 bgn, 100 BASE-T sACN, Art-Net
SHoW IDs
90
Latency
4 ms average
RF Sensitivity
-95dBm
RDM Features
RDM Proxy, RDM Responder
Use Environment
Indoor
Ambient Temperature Range
0° C to 40° C
IP Rating
IP50
Compliance
FCC, IC, ETL
Warranty
One year
