City Theatrical 5910 Wireless DMX Multiverse Transmitter, 900MHz/2.4GHz, NA Only

The Multiverse Transmitter (5910) opens a new world in wireless DMX/RDM. Its Ethernet input allows it to take in Streaming ACN (sACN) or Art-Net and to transmit between eight and 10 user-selectable universes of DMX/RDM, depending on the type of Multiverse Transmitter product used, with the ability to use less radio energy than a present-day single universe wireless DMX transmitter.

The Multiverse Transmitter has a Bluetooth radio receiver built in that allows it to communicate with City Theatrical’s DMXcat app from the user’s smartphone. This gives the user smartphone control of any lighting fixture that is part of the Multiverse setup, whether it is a lighting fixture with a Multiverse Module inside, a lighting fixture receiving its data from a Multiverse SHoW Baby or Multiverse Node, or any wired fixture downstream of those devices.

The Multiverse Transmitter is Wi-Fi enabled, allowing for communication and control from tablet-based Wi-Fi lighting controllers like Luminair.

Key Features

• Four radios: Bluetooth and Wi-Fi for inputs, 900MHz and 2.4GHz for Multiverse wireless DMX/RDM output
• Ethernet input for sACN and Art-Net
• All setup and user choices made with our free DMXcat app
• Rugged cast aluminum enclosure
• A hanging bracket is included for hanging from a pipe or truss
• Additional user control via DMXcat app or Luminair

Technical Specifications

Physical Specifications
Length
7.75” (196.9mm)
Width
4” (101.5mm)
Height
1.85” (47mm)
Weight
1.25Lbs (0.57kg)
Construction
Die Cast Aluminum
Frequency Range
2400 – 2480 MHz; 902 – 928 MHz
Connection Specifications
Antenna(s)
RP-SMA female
AC
powerCON TRUE1 in/thru
DC
Locking DC Jack, 5.5mm x 2.1mm, center positive, 12.1mm mating depth; EtherCON
Functionality
Wi-Fi Capability
802.11 b/g/n
User Interface
DMXcat app (for iPhone, Android or Amazon Fire), free download
Version Control
Free firmware updates on product pages of CTI website
RDM Configuration
Configurable over RDM
RDM Features
RDM Proxy, RDM Responder
Power
High Voltage Input
100-240VAC 50/60 Hz
Low Voltage Input
5-30VDC
Power over Ethernet (PoE)
Class 0
Maximum Wattage
0.5W
Radio Technology
Latency
4 ms average
RF Sensitivity
-95dBm
Loss of Data Behavior
Output stops
Broadcast Power
3.2mW, 10mW, 32mW, 100mW
Broadcast Modes
Adaptive, Full, Low, Mid, High, Max
DMX Burst Mode
Auto Dynamic
Show IDs
237
Supported Protocols
RDM ANSI E1.20 via Art-Net / DMXcat
Streaming ACN (sACN)
Art-Net I, II, and III
Product Information
Use Environment
Indoor
Ambient Temperature Range
0 C to 40° C
IP Rating
IP50
Compliance
FCC, IC, ETL
