Audio-Technica ATW-3211N894XTH EE1 3000 Series Network Wireless Cardioid Earset System, EE1 530-590 MHz, Beige

The Audio-Technica ATW-3211N894XTH EE1 3000 Series Network Wireless Cardioid Earset System is a cutting-edge audio solution designed for professional use in even the most challenging RF environments. Optimized to operate within the congested UHF spectrum, this fourth-generation wireless system combines unmatched versatility, ease of setup, and reliability. Whether you’re a live performer, public speaker, or sound engineer, the ATW-3211N894XTH ensures clear, interference-free audio transmission up to a range of 300 feet (100 meters).

This wireless system operates in the EE1 frequency band (530-590 MHz) and offers an extraordinary 60 MHz tuning range, which is more than double that of previous models. The system features a network-enabled receiver (ATW-R3210N) that provides comprehensive monitoring and control capabilities via the Wireless Manager software. With the ability to scan and select frequencies on the receiver and sync with the transmitter using IR sync functionality, the system offers user-friendly operation and exceptional control. Additionally, the unique multifunction button on the transmitter allows for quick frequency changes should unexpected interference occur, ensuring a seamless performance in any setting.

Key Features

• Extremely wide 60 MHz UHF tuning bandwidth for maximum versatility in congested RF environments
• Available in two frequency bands: DE2 (470-530 MHz) and EE1 (530-590 MHz)
• Multifunction button on transmitters for quick frequency switching to mitigate interference
• Network-enabled system with ATW-R3210N receiver for remote control and monitoring
• True Diversity operation to reduce audio dropouts
• Auto Squelch to automatically adjust settings for optimal range and interference minimization
• Frequency scan and IR sync for simple setup
• Dual-mode receiver display for standard or performance view
• Transmitters and receivers equipped with OLED screens for clear readouts
• Handheld transmitter with low handling noise and compatible with various interchangeable microphone capsules
• Rugged cH-style connector on body-pack transmitter for secure connections to mics and cables
• Tactile mute toggle switch on body-pack transmitter for clear mute status indication
• Charging terminals compatible with optional smart charging docks
• Antenna power for powered antennas and in-line RF devices
• Ground-lift switch to eliminate hum caused by ground loops
• Balanced and unbalanced audio output jacks

Specifications

• Operating Frequencies Band EE1: 530.000 to 589.975 MHz (2400 frequencies)
• Minimum Frequency Step: 25 kHz
• Modulation Mode: FM
• Maximum Deviation: ATW-T3201: ±38 kHz, ATW-T3202: ±36 kHz
• Dynamic Range: ATW-T3201 Mic input: > 115 dB, Inst input: > 112 dB; ATW-T3202: > 115 dB
• Total Harmonic Distortion: <1.0%
• Operating Range: 100 m (328 ft)
• Operating Temperature Range: -5° C to +45° C (23° F to 113° F)
• Frequency Response: ATW-T3201: 31 Hz to 15,500 Hz, ATW-T3202: 25 Hz to 16,700 Hz
• Maximum Simultaneous Use: 40 Channels per band
• Receiving System: True Diversity
• Image Rejection: 60 dB nominal
• RF Sensitivity: 20 dBuV at 60 dBA S/N ratio
• Antenna Power: 12 V DC, 160 mA
• Maximum Output Level: XLR, balanced: +14 dBV; 6.3 mm, unbalanced: +8 dBV
• Antenna Input: BNC-type, 50 ohms
• Power Supply: 100-240V AC to 12V DC 1A
• Dimensions: 210.0 mm x 191.0 mm x 43.4 mm
• Net Weight: 1100 g

Package Contents

• Two flexible UHF antennas
• AC adapter (country dependent)
• Rack-mount adapters
